Frequency Range (-10 dB) 70 Hz – 15 kHz Horizontal Coverage (-6 dB) 100º Nominal Impedance 100v Transformer Taps 70 V Tap1, 1.5 W. Tap2, 3 W. Tap3 6 W. Transformer Taps 100 V Tap1, 3 W. Tap2, 6 W. Tap3 X. On-axis Sensitivity 1W/1 m 89 dB SPL Recommended Amplifier IA-402 IA-404 Connectors Audio Input Connector Spring Terminals Audio Output Connector Spring Terminals Enclosure Enclosure Geometry Round Color White Cut Out Diameter 169 mm (6,7 in) Depth 70 mm (2,8 in) Net Weight 0,9 kg ( 2,0 lb ) Shipping Carton Dimensions ( H x W x D ) 250 x 230 x 370 mm 9,8 x 9,1 x 14,6 in Shipping Weight 1,0 kg ( 2,2 lb )

Frequency Range (-10 dB) 70 Hz – 15 kHz
Horizontal Coverage (-6 dB) 100º
Nominal Impedance 100v
Transformer Taps 70 V Tap1, 1.5 W. Tap2, 3 W. Tap3 6 W.
Transformer Taps 100 V Tap1, 3 W. Tap2, 6 W. Tap3 X.
On-axis Sensitivity 1W/1 m 89 dB SPL
Recommended Amplifier IA-402
IA-404
Connectors
Audio Input Connector Spring Terminals
Audio Output Connector Spring Terminals
Enclosure
Enclosure Geometry Round
Color White
Cut Out Diameter 169 mm (6,7 in)
Depth 70 mm (2,8 in)
Net Weight 0,9 kg ( 2,0 lb )
Shipping
Carton Dimensions ( H x W x D ) 250 x 230 x 370 mm
9,8 x 9,1 x 14,6 in
Shipping Weight 1,0 kg ( 2,2 lb )

Tipo : Embutir ;
Impedância : 100v ;
SKU: 10213020
